BUTTERFLY VALVES, LUG TYPE, DIN PN16
LOCK LEVER OPERATED, WITH CLASS CERTIFICATE| DN | Code | Body | Stem | Disc | Seat | PCD | Holes no. x Dia | L |
|---|---|---|---|---|---|---|---|---|
| 50 | 754446 | GGG40.3 | Stainless Steel | Alu-Bronze | NBR | 125 | 4 | 18 | 43 |
| 65 | 754447 | GGG40.3 | Stainless Steel | Alu-Bronze | NBR | 145 | 4 | 18 | 46 |
| 80 | 754448 | GGG40.3 | Stainless Steel | Alu-Bronze | NBR | 160 | 8 | 18 | 46 |
| 100 | 754449 | GGG40.3 | Stainless Steel | Alu-Bronze | NBR | 180 | 8 | 18 | 52 |
| 125 | 754450 | GGG40.3 | Stainless Steel | Alu-Bronze | NBR | 210 | 8 | 18 | 56 |
| 150 | 754451 | GGG40.3 | Stainless Steel | Alu-Bronze | NBR | 240 | 8 | 22 | 56 |
| 200 | 754452 | GGG40.3 | Stainless Steel | Alu-Bronze | NBR | 295 | 12 | 22 | 60 |
