STORM VALVES, VERTICAL PATTERN, JIS 5K F3060

CAST STEEL BODY, STAINLESS STEEL 316 STEM; BRONZE DISC & SEAT
WITH CLOSING DEVICE, WITH CLASS CERTIFICATE

DN	Code	Flange OD	PCD	Holes no. x Dia	Face to Face
50	754241	130	105	4 \| 15	210
65	754242	155	130	4 \| 15	240
80	754243	180	145	4 \| 19	260
100	754244	200	165	8 \| 19	280
125	754245	235	200	8 \| 19	330
150	754246	265	230	8 \| 19	360
